QBT2131 א.נ יעף - סורק ברקוד

Specifications
CORDLESS COMMUNICATIONS
BLUETOOTH WIRELESS TECHNOLOGY
    Piconet: Max. Readers per Radio Receiver Using
    Commercial Dongle: 7; Using Cradle: 1
PROFILES
    HID (Human Interface Device)
    SPP (Serial Port Profile)
PROTOCOL Bluetooth 3.0 Certified Class 2
RADIO FREQUENCY 2.4 GHz
RADIO RANGE (OPEN AIR) 25.0 m / 82.0 ft
Range distances are measured using the base
station. Range with connection to other
Bluetooth peripherals may show different
results.
SECURITY Data Encryption; Scanner Authentication

DECODING CAPABILITY
1D / LINEAR CODES Autodiscriminates all standard 1D codes
including GS1 DataBar™ linear codes.
STACKED CODES EAN/JAN Composites; GS1 DataBar Composites;
                                    GS1 DataBar Expanded Stacked; GS1 DataBar
                                    Stacked; GS1 DataBar Stacked Omnidirectional;
                                    UPC A/E Composites

ELECTRICAL
BATTERY Battery Type: Lithium-Ion 1400 mAh
                    Charge Time: External Power: 4 hrs @ 12 VDC;
                    Reads per Charge: 30,000 +
INPUT VOLTAGE 4.75 - 14 VDC

ENVIRONMENTAL
AMBIENT LIGHT 0 - 120,000 lux
DROP RESISTANCE Withstands repeated drops from 1.5 m / 5.0 ft
onto a concrete surface.
ESD PROTECTION (AIR DISCHARGE) 16 kV
HUMIDITY (NON-CONDENSING) 90%
PARTICULATE AND WATER SEALING IP42
TEMPERATURE Operating: 0 to 50 °C / 32 to 122 °F
                                Storage/Transport: -40 to 70 °C / -40 to 158 °F

INTERFACES
INTERFACES Keyboard Wedge / OEM (IBM) USB / RS-232 / USB

PHYSICAL CHARACTERISTICS
COLORS AVAILABLE Black, White
DIMENSIONS 16.3 x 9.1 x 4.1 cm / 6.4 x 3.6 x 1.6 in
WEIGHT Reader: 190 g / 6.7 oz
Base/Charger: 221 g / 7.8 oz

READING PERFORMANCE
FIELD OF VIEW 56° +/- 2°
LIGHT SOURCE Red LED 610 - 650 nm
PRINT CONTRAST RATIO (MINIMUM) 25%
READ RATE 400 reads / sec.
READING ANGLE Pitch: +/- 65°; Roll (Tilt): +/- 45°;
                                   Skew (Yaw): +/- 70°
READING INDICATORS Beeper (Adjustable Tone and Volume);
Datalogic ‘Green Spot’ Good Read Feedback; Good Read LED
RESOLUTION (MAXIMUM) 0.102 mm / 4 mils (Linear Codes)

READING RANGES
TYPICAL DEPTH OF FIELD Minimum distance determined by symbol length
and scan angle.
Printing resolution, contrast, and ambient light
dependent.
4 mils: 3.0 to 11.0 cm / 1.2 to 4.3 in
5 mils: 2.0 to 15.0 cm / 0.8 to 5.9 in
7.5 mils: 2.0 to 25.0 cm / 0.8 to 9.8 in
10 mils: 2.0 to 36.0 cm / 0.8 to 14.2 in
13 mils: 1.0 to 45.0 cm / 0.4 to 17.7 in
20 mils: 4.0 to 70.0 cm / 1.5 to 27.5 in

SAFETY & REGULATORY
AGENCY APPROVALS The product meets necessary safety and
regulatory approvals for its intended use.
The Quick Reference Guide for this product can
be referred to for a complete list of certifications.
ENVIRONMENTAL COMPLIANCE Complies to China RoHS; Complies to EU RoHS

UTILITIES
DATALOGIC ALADDIN™ Datalogic Aladdin configuration program is
available for download at no charge.
OPOS / JAVAPOS JavaPOS Utilities are available for download at no
charge.
OPOS Utilities are available for download at no
charge.
REMOTE HOST DOWNLOAD Lowers service costs and improves operations.

WARRANTY
WARRANTY 3-Year Factory Warranty

עמוד הבית סורקים קורא ברקוד אלחוטי QBT2131

DataLogic QuickScan QBT2131 Affordable Cordless BT 1D linear imager providing standard BT connectivity and unique wireless features

קורא ברקוד אלחוטי Bluetooth DataLogic
