Communications
Voice
PTT (client included), VoIP-ready models (VoIP client not included),
high-quality speakerphone; wireless (Bluetooth) headset support; PTT
headset support; handset/speakerphone modes
WLAN
Radio: Tri-mode IEEE® 802.11a/b/g/n/r
WPAN (Bluetooth Support)
Class II, v2.1 with Enhanced Data Rate (EDR), Integrated antenna
Network connections
Micro USB 2.0 OTG connector
Performance
Characteristics
Operating system (OS)
Android 4.1.1
Technology
Interactive Sensor Technology (IST)
Motion Sensor: 3-axis accelerometer provides motion-sensing for dynamic
screen orientation and power management
Light Sensor: Automatically adjusts display backlight brightness
Proximity Sensor: Prevents unwanted key presses in handset mode
Data capture options
Imager: SE4500-DL
Camera: Rear-facing 8 MP auto-focus with aiming
Payment Transactions: Integrated Magnetic Stripe Reader (MSR) with
encrypted head (optional)
Memory (Flash/RAM)
1GB RAM / 8GB Flash
Processor (CPU)
800 MHz OMAP4 Dual-Core Processor
Physical Characteristics
Dimensions (HxWxD)
With Magnetic Stripe Reader (MSR): 5.66 in. H x 2.87 in. W x 1.25 in. D
(143.9 mm H x 72.8 mm W x 31.8 mm D)
Without Magnetic Stripe Reader: 5.66 in. H x 2.87 in. W x 0.79 in. D
(143.9 mm H x 72.8 mm W x 20.1 mm D)
Weight
With battery and MSR: 9.38 oz./266.1 g
With battery, without MSR: 9.09 oz. / 257.7 g
Display type
4.3” capacitive
Display resolution
480x800; 300 NIT
Touch panel
Capacitive dual-touch
Notification
Vibrator, LED, Audio notifications
Audio options
Microphone, Speaker, Headset jack, Stereo audio through Bluetooth
stereo headsets
LED backlight
Yes
Power
Battery
Rechargeable Lithium Ion 3.7V, 2680 mAh Smart battery
Backup battery
Rechargeable Ni-MH battery, 15 mAh, 3.6 V nominal (not user-accessible
or replaceable)
Regulatory Specifications
WLAN
EN 300 328, EN 301 893, FCC Part 15.247, 15.407, RSS-210
Laser safety
EN 60825-1, IEC 60825-1, 21CFR1040.10, IEC/EN 62471
EMI/RFI
EN 301 489-1, 17, EN 55022 (Class B), EN 55024, EN 61000-3-2, EN
61000-3-3, IEC/EN 60601-1-2, 47 CFR Part 15, Subpart B, Class B, ICES
003 Issue 5, Class B
Electrical safety
UL 60950-1, EN 60950-1, IEC 60950-1, CAN/CSA-C22.2 No. 60950-1-07
Environmental
RoHS Directive 2002/95/EEC
RF exposure
EN 50360, EN 62479, EN 62311, FCC 47CFR Part 2; OET Bulletin 65c, RSS
102 Issue 4
User Environment
Operating temperature
0° C to 50° C / 32° F to 122° F
Storage temperature
-40° C to 70° C / -40° F to 158° F
Drop specification
Multiple 4 ft. / 1.2m drops per MIL STD 810G; multiple 3 ft./ 0.9m
drops to tile
Environmental sealing
IP54
Humidity
5% to 85% RH non-condensing
Electrostatic discharge (ESD)
± 15kV Air, ± 8kV contact, ± 2kV charge body
