Printer Specifications
Print Method Thermal Transfer / Direct Thermal
Resolution 203 dpi (8 dots/mm)
Print Speed Up to 6 IPS (152 mm/s)
Print Width 4.25” (108 mm)
Print Length Min. 0.16” (4 mm) Max. 68” (1727 mm)
Processor 32 Bit RISC CPU
Memory Flash 8 MB Flash (4 MB for user storage)
SDRAM 16 MB SDRAM
Sensor Type Adjustable reflective sensor
2 fixed transmissive sensors, central aligned
DimensionLength 11.2” (285 mm)
Height 6.8” (171 mm)
Width 8.9” (226 mm)
Weight 6 lbs (2.72 Kg) ,excluding consumables
MediaTypes Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width 1” (25.4 mm) Min. - 4.64” (118 mm) Max.
Thickness 0.003” (0.06 mm) Min. - 0.01” (0.25 mm) Max.
Label Roll Diameter Max. 5” (127 mm)
Core Diameter 1” (25.4 mm), 1.5” (38.1mm), 3” (76.2mm)
Ribbon
Types Wax, wax / resin, resin
Length 981’ (300 m)
Width 1.18” Min. - 4.33” (30 mm - 110 mm) Max.
Ribbon Roll Diameter 2.67“ (68 mm)
Core Diameter 1” (25.4 mm)
Printer Language EZPL, GEPL, GZPL auto switch
Software
Label Design Software GoLabel (for EZPL only)
Driver MAC, Linux, Windows 2000 / XP / VISTA / Windows 7 / Windows 8.1
DLL Win CE, .NET, Andriod, Windows Mobile, Windows 2000 / XP / VISTA / Windows 7 / Windows 8.1
Resident FontsBitmap Fonts
- Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
- Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
- Bitmap fonts 8 times expandable in horizontal and vertical directions
TTF Fonts CG Triumvirate™ (Bold / Italic / Underline ). 0°,90°, 180°, 270° rotatable
Download Fonts Bitmap Fonts Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian Fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
TTF Fonts 90°, 180°, 270° rotatable
Barcodes
1-D Bar codes Code 39, Code 93, EAN 8 / 13 (add on 2 & 5), UPC A / E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping
Be arer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC / EAN-128 K-Mart,
Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar,
German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit,
Standard 2 of 5, Industrial 2 of 5, Logmars, Code 11, Code 49, Cadablock
2-D Bar codes PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code
Code Pages CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode UTF8、UTF16BE、UTF16LE
Graphics Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software
Interfaces USB Device (B-Type), Ethernet port (RJ-45)
Control Panel One Tri-color LED: Power (Green, Orange and Red)
Function Key: FEED
Power Auto Switching 100-240VAC, 50-60Hz.
EnvironmentOperation Temperature 41°F to 104°F (5°C to 40°C)
Storage Temperature -4°F to 122°F (-20°C to 50°C)
Humidity Operation 30-85%, non-condensing.
Storage 10-90%, non-condensing.
Agency ApprovalsCE (EMC), FCC Class A, CB, CCC, UL, cUL
Options & AccessoriesExternal label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder T10
