Specifications
Light source 660nm
Visible Red LED
Optical system 2048 pixel
CCD(Charge-coupled device)
Depth of scan field 0 – 150 mm(Code 39,
PCS = 90%, 20mils)
Scanning width 75 mm at contact
Scan speed 200 scans/sec
Resolution 0.1 mm (4mils) Code39, PCS =
90%, on contact
Print contrast 45% (30% programmable)
Scanning angle Front: 60° Rear: 60° Yaw:
75°
Decode capability Auto discriminates all
standard barcode; Other symbologies can be ordered optionally (2D
symbologies for 8250)
Beeper operation 7 tones or no beep
Indicator Blue LED
Length 182 mm
Width-handle 26 mm
Width-head 90 mm
Depth-handle 49 mm
Depth-head 35 mm
Weight 120 g (cable not included)
Connector type RJ-45 phone jack connector
Case material ABS
Input voltage 5 VDC ± 0.25V
Power - operating 1250mW
Power - standby 300 mW
Current - operating 250 mA @ 5 VDC
Current - standby 60 mA @ 5 VDC
Agency Listing UL, FCC Class A, CE
Operating Temperature 0° to 45° (32° to
113° )
Storage -20° to 60° (-4° to 140° )
Humidity 5% to 90% relative humidity,
non-condensing
Light level Up to 20000 Lux
Shock 1.2m drop onto concrete
Programming method Manual (Reading special
barcode)DOS command through RS-232
Programmable characteristics
Code type selection, check digit selection, Decoding option,
Transmitted character delay, header selection, trailer selection,
message suffix, good read beep tone and volume, scanner trigger
selection Keyboard emulation type(intermessage delay, keyboard type and
keyboard language) Serial interface type ( ACK/NAK, Xon/Xoff, RTS/CTS,
good read LED control, start/stop bits)
