Specifications
Light source 630 nm
visible red LED
Optical system 2048 pixel CCD
(charge-coupled device)
Depth of scan field Up to 600mm ( code 39,
PSC=90%, 20mils)
Scanning width 160 mm
Scan speed 450 scans/sec
Current - sleep mode 25 mA @ 5VDC
Resolution 0.1mm(4mils) - Code 39, PCS=90
%, on contact
Print contrast 30% or more
EMC UL,FCC Class B,CE
Scanning angle Front: 60° Rear: 60° Yaw:
75°
Decode capability Autodiscriminates all
standard one-dimension barcodes; other symbologies can be ordered
optionally
Beeper operation 7 tones or no beep
Indicator Green & Red LED
Length 164 mm
Cushion material Double injection
Width-handle 30 mm
Width-head 78 mm
Depth-handle 56 mm
Depth-head 35 mm
Weight 176 g (cable not included)
Connector type RJ-45 phone jack connector
Case material ABS (over molded at contact
pointed)
Input voltage 5 VDC ± 0.25V
Shock resistance 0°C to 50°C (32°C to
122°C)
Power - operating 800 mW
Power - standby 350 mW
Current - operating 160 mA @ 5 VDC
Current - standby 70 mA @ 5 VDC
DC transformers Class 2; 5VDC @ 450 mA
Storage -20°C to 70°C (-4°C to 158°C)
Humidity 5% to 90% relative humidity,
non-condensing
Light level Up to 70000 Lux
Shock 1.5m drop onto concrete
Programming method Manual (reading special
barcode) DOS command through RS-232, Windows configuration program
Contaminants Sealed to resist airborne
particulate contaminants
Program upgrade Enabled by build-in flash
memory
Programmable char.
Code type selection, check digit selection Decoding option Transmitted
character delay, Header selection, trailer selection, message suffix,
good read beep tone and volume, scanner trigger selection Keyboard
emulation type (intermessage delay, keyboard type and keyboard
language).Serial interface type (ACK/NAK, Xon/Xoff, RTS/CTS, good read
LED control, start/stop bits)
