Specifications
Performance
Light source 620 nm Red LED
Optical Type Linear Imager
Depth of field 40 - 480 mm
Scan Rate 325 Scans/Sec
Scanning angle Pitch: ±60°; Roll: ±30°; Skew: ±60°
Minimum Bar Width 0,076 mm (3 mil)
Indicators (LED) LED and Beep volume
Print Contrast ≥%30
System Interfaces PS/2, RS-232C and USB
Physical
Height 68 mm
Length 145 mm
Width 101 mm
Weight 120 Gram
Electrical
Operating Voltage 5VDC ±%5
Power consumption 345mW
Current Standby Current: 10 mA ±1mA
perating Current: 70,4 mA (Max.96,8 mA)
Environmental
Operating temperature -20 °C ~ 50 °C
Storage Temperature -40 °C ~ 85 °C
Humidity %5 ~ %95 (non-condensing)
ESD ±8 KV (contact discharge); ±10 KV (air discharge)
Drop 1.2m drop to concrete
Sealing IP42
Barcode Types
Supported Barcode Types
AIM128, Code 11, Code 32, Code 39, Code 93, Code 128, Codabar, COOP 25,
Deutsche 12, Deutsche 14, EAN-8, EAN-13, Febraban, GS1-128, GS1 Databar
(RSS), ISBN, ISSN, ITF-6, ITF-14, MSI-Plessey, Plessey, UPC-A, UPC-E,
Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, Standard 2 of 5.
Certifications
Certifications FCC Part15 Class B, CE EMC Class B
