Specifications
Mechanical
Dimensions
6.50 x 2.76 x 4.23" /16.51 x 7.01 x 10.74 cm
Weight
Scanner: 6.0 ozs. / 170 g
Cable (32"/81 cm): 6.2
ozs / 176 g
Cable length options
Collapsed: 32" / 81 cm, Max. Working:
72" / 183 cm
Collapsed: 80" / 203 cm, Max. Working:
120" / 305 cm
(For other cable options, contact your
PSC sales representative.)
Optical
Light Source
Visible Laser Diode (VLD), 680 nm-nominal (650 nm-optional)
Scan system
Electromagnetic dithering mirror
Rate 42
scans/sec. (nominal)
| Label Density |
Range |
| 5 mil |
1.0
to 3.0" / 2.5 to 7.6 cm |
| 7.5 mil |
0.5 to 6.0" / 1.3 to
15.2 cm |
| 10 mil |
0.0
to 9.0" / 0.0 to 22.9 cm |
| 13 mil |
0.0
to 13.0" / 0.0 to 33.0 cm |
| 20 mil |
up to
20.0" / up to 48.3 cm |
Resolution 5
mils / 0.13mm
Print contrast ratio
30% minimum
Pitch ±65°
Skew ±55°
Scan angle
46°
Ambient light immunity
Artificial light: 1,200
foot candles / 12600 Lux
Sunlight: 8,000 foot candles / 84000 Lux
Electrical
NOTE: Specifications
using the 680 nm laser diode & cable
Operating Voltage
Undecoded: 4.2 V to 14 VDC
Decoded: 4.5 V to 14 VDC
Operating current -
nominal
Undecoded: 70 mA to 5 VDC
Decoded: 120 mA to 5 VDC
Idling current - nominal
Undecoded: 10 µA to 5 VDC
Decoded: 23 mA to 5 VDC
Decoded, lowest power mode: 14 mA to 5
VDC
Environmental
Temperature
Operating: 32° to 113° F /
0° to 45° C
Storage: -22° to 149° F /
-30° to 65° C
Humidity 5 to 95% NC
Shock (at 23°C) Withstands multiple 5.0' / 1.5 m drops
onto concrete / 100+ drops to countertop
Vibration MIL-STD-810E
Water & Dust Resistant, IEC529 rating IP53DW
Decoding Capability
- UPC A, E / EAN 8,13 / JAN 8, 13 (Codes add-ons P2
/ P5, Code 128)
- Code 128/EAN 128
- Codabar
- Pharmacode 39
- Code 93
- Interleaved 2/5
- Standard 2/5, IATA
- Code 39
- MSI/Plessey
Communications
AutoSelect™ cable determines active interface
- IBM 4682/92 (Port E)
- IBM 4683/84 (Ports 5B & 9B) and Wand Emulation
- IBM 4693/94 (Ports 5B & 9B) and Wand Emulation
- IBM 46XX / USB Embedded with USB Single Cable
- RS232 & IBM 46xx
- RS232 & Wand Emulation
- RS232 & Standard Keyboard Wedge
- OCIA (formats SP & NCR) & RS232
- Standard Keyboard Wedge & Wand Emulation
- Universal Keyboard Wedge
- Undecoded
Safety/Regulatory
Electrical - Complies to:
Gost R
TÜV
UL
cUL
Emissions - Complies to:
FCC-A
EN 55022-B
BCIQ CNS 13438
AS/NZS 3548
VCCI-B
Laser classification
CDRH Class IIa (ATTENTION: Laser Radiation - do not stare into beam)
IEC 60825 Class 1 & 2
